Internal status bits, corresponding to the state of discrete outputs, are also available to the program. In the example, the physical state of the float switch contacts must be considered when choosing "normally open" or "normally closed" symbols in the ladder diagram. Both float switches normally closed open their contacts when the water level in the tank is above the physical location of the switch. When the water level is below both switches, the float switch physical contacts are both closed, and a true logic 1 value is passed to the Fill Valve output.

Water begins to fill the tank.

Automating Manufacturing Systems

The internal "Fill Valve" contact latches the circuit so that even when the "Low Level" contact opens as the water passes the lower switch , the fill valve remains on. Since the High Level is also normally closed, water continues to flow as the water level remains between the two switch levels. Once the water level rises enough so that the "High Level" switch is off opened , the PLC will shut the inlet to stop the water from overflowing; this is an example of seal-in latching logic.


  1. To report this review as inappropriate, please complete this short form..
  2. Hinchliffe A Chemical Modelling - Applications and Theory.
  3. Automated Manufacturing Systems with PLCs?
  4. Custom Automated Manufacturing Systems.
  5. Automating manufacturing systems with plcs pdf.

The output is sealed in until a high level condition breaks the circuit. After that the fill valve remains off until the level drops so low that the Low Level switch is activated, and the process repeats again. A complete program may contain thousands of rungs, evaluated in sequence. A complete program scan may take only a few milliseconds, much faster than changes in the controlled process.

Programmable controllers vary in their capabilities for a "rung" of a ladder diagram. Some only allow a single output bit. There are typically limits to the number of series contacts in line, and the number of branches that can be used. Each element of the rung is evaluated sequentially.

If elements change their state during evaluation of a rung, hard-to-diagnose faults can be generated, although sometimes as above the technique is useful. Some implementations forced evaluation from left-to-right as displayed and did not allow reverse flow of a logic signal in multi-branched rungs to affect the output. The functionality of the PLC has evolved over the years to include sequential relay control, motion control, process control , distributed control systems , and networking.

The data handling, storage, processing power, and communication capabilities of some modern PLCs are approximately equivalent to desktop computers. Desktop computer controllers have not been generally accepted in heavy industry because the desktop computers run on less stable operating systems than PLCs, and because the desktop computer hardware is typically not designed to the same levels of tolerance to temperature, humidity, vibration, and longevity as the processors used in PLCs.

Operating systems such as Windows do not lend themselves to deterministic logic execution, with the result that the controller may not always respond to changes of input status with the consistency in timing expected from PLCs. Desktop logic applications find use in less critical situations, such as laboratory automation and use in small facilities where the application is less demanding and critical.

The most basic function of a programmable controller is to emulate the functions of electro-mechanical relays. Discrete inputs are given a unique address, and a PLC instruction can test if the input state is on or off. Just as a series of relay contacts perform a logical AND function, not allowing current to pass unless all the contacts are closed, so a series of "examine if on" instructions will energize its output storage bit if all the input bits are on.

Similarly, a parallel set of instructions will perform a logical OR. In an electro-mechanical relay wiring diagram, a group of contacts controlling one coil is called a "rung" of a "ladder diagram ", and this concept is also used to describe PLC logic.

Automating Manufacturing Systems with PLCs

Some models of PLC limit the number of series and parallel instructions in one "rung" of logic. The output of each rung sets or clears a storage bit, which may be associated with a physical output address or which may be an "internal coil" with no physical connection. Such internal coils can be used, for example, as a common element in multiple separate rungs.

Unlike physical relays, there is usually no limit to the number of times an input, output or internal coil can be referenced in a PLC program. Some PLCs enforce a strict left-to-right, top-to-bottom execution order for evaluating the rung logic. This is different from electro-mechanical relay contacts, which in a sufficiently complex circuit may either pass current left-to-right or right-to-left, depending on the configuration of surrounding contacts. The elimination of these "sneak paths" is either a bug or a feature, depending on programming style.

More advanced instructions of the PLC may be implemented as functional blocks, which carry out some operation when enabled by a logical input and which produce outputs to signal, for example, completion or errors, while manipulating variable internally that may not correspond to discrete logic. The main function of a timer is to keep an output on for a specific length of time. A good example of this is a garage light, where you want power to be cut off after 2 minutes so as to give someone time to go into the house.

A Delay-OFF timer activates immediately when turned on, counts down from a programmed time before cutting off, and is cleared when the enabling input is off.
